1、 Practical application Eddy current sensor system is widely used in electric power, petroleum, chemical industry, metallurgy and other industries and some scientific research institutions. Online measurement and protection of radial vibration, axial displacement, Keyphasor, shaft speed, differential expansion, eccentricity, rotor dynamics research and part size inspection of large rotating machinery shafts such as steam turbine, water turbine, blower, compressor, air separation unit, gearbox and large cooling pump. Axial displacement measurement The measurement of axial displacement can indicate the axial clearance or relative instantaneous displacement change between rotating parts and fixed parts, so as to prevent the damage of the machine. ●wear and failure of thrust bearing ● wear and failure of balance piston ●looseness of thrust flange ● locking of coupling, etc. Vibration measurement By measuring the radial vibration, we can see the working state of the bearing and the imbalance and medium mechanical failure of the rotor. Eccentricity measurement Eccentricity is the measurement of shaft bending at low speed, which can be caused by the following conditions: ●Original mechanical bending · bending caused by temporary temperature rise ● in the static state, there must be some downward bending, sometimes called gravity bending. Differential expansion measurement For steam turbine generator units, during startup and shutdown, due to different metal materials, different thermal expansion coefficients and different heat dissipation, the thermal expansion of the shaft may exceed that of the shell. Speed measurement For all rotating machinery, it is necessary to monitor the rotating speed of the rotating machinery shaft. The rotating speed is an important index to measure the normal operation of the machine. 2、Installation requirements Axial vibration measurement When the radial vibration of the shaft needs to be measured, the diameter of the shaft is required to be more than three times the diameter of the probe. Two sensor probes shall be installed at each measuring point at the same time, and the two probes shall be installed on the same plane on both sides of the bearing, separated by 90 º ± 5 º. Since the bearing cover is generally divided horizontally, the two probes are usually installed at 45 º on each side of the vertical centerline. From the end of the prime mover, they are respectively defined as X probe (horizontal direction) and Y probe (vertical direction). The X direction is on the right side of the vertical centerline and the Y direction is on the left side of the vertical centerline. Axial displacement measurement When measuring the axial displacement of the shaft, the measuring surface should be integral with the shaft. This measuring surface is a probe ring with the center line of the probe as the center and 1.5 times the width.

Xiamen kehao automation co., Ltd. is a professional manufacturer of industrial instruments, advanced technology and CE, ROHS, ISO certification can ensure the quality. Our own production plant can ensure price advantage.at present, the company's trade scale isexpanding day by day, customers all over the world, with good reputation has been the trust of customers at home and abroad, our enthusiasm hope: you and I hand in hand, create a better future!

1.Low MOQ: It can meet your promotional business very well. 2.OEM Accepted : We can produce any your design as long as you provide us the drawing. 3.Good Service : We treat clients as friend. 4.Good Quality :We have strict quality control system .Good reputation in the foreigner market 5.Fast & Cheap Delivery: We have big discount from forwarder (Long Contract)
