| Pressure Range | -1-0-1 Bar.....600 Bar Optional | ||||
| Accuracy | ≤ ±1.0%F.S ≤ ±0.5%F.S ≤ ±0.25%F.S (Customized) | ||||
| Diaphragm material | Piezoresistive Flush Ceramic | ||||
| Electronic Wire | 2 Wires | 3 Wires | |||
| Output | 4~20mA | 0~5V | 0~10 V | 0.5~4.5 V | By Customized |
| Power Supply | 12~36 V DC | 12~36 V DC | 15~36Vdc | 5 V DC | By Customized |
| Insulate resistance | >100M Ω @50V | ||||
| Electronic connection | Terminal Box (DIN43650 Hirschman Connector, IP65) Directly sealed cable IP67; M12 4 Pins connector IP65; Small Hirschman Connector; connection are optional. | ||||
| Pressure connect port | 1/8’’NPT male, 1/4’’NPT male 1/4’’NPT Female, G1/2’’ male, G1/4’’male/female, 7/16’’-20 UNF male/female are optional. (by Customized) | ||||
| Response time | ≤10ms | ||||
| Certificate approving | CE Certificate. | ||||
| EMC Standard | electromagnetic radiation:EN50081-1/-2 electromagnetic susceptibility:EN50082-2 | ||||
| Water Proof | IP65 to IP67 | ||||
| Weight | Net weight is about 0.10KG, Full Packing weight is about 0.5KG (Included 3 Meters Cable) | ||||
Device real-time monitoring query
The equipment uses RS485 communication connection acquisition card to achieve real-time recording, monitoring and query
